The correct answers are A and B. In SRX chassis clustering, the fabric link, represented by fab interfaces, is the data-plane connection between the two cluster nodes. Juniper describes the fabric as the back-to-back data connection used when traffic on one node must be processed on the other node or must exit through an interface on the other node; session-state information also passes over the fabric. This is especially visible in active/active clustering, where ingress and egress interfaces can reside on different nodes and transit traffic must cross the fabric link.

Option B is also correct because the fabric link still exists in active/passive clustering for cluster data-plane synchronization and inter-node state handling, even though active/passive designs minimize fabric transit traffic because only one node normally forwards traffic at a time. Juniper specifically states that active/passive mode minimizes traffic over the fabric link, not that the fabric link is unused.

Options C and D are not the intended answers. The cluster is identified by a configured cluster ID, and each chassis is identified by a node ID, but the fabric interface names themselves are not where the cluster ID is reflected. Reference topics: HA Clustering, fabric link, active/active clustering, active/passive clustering, session synchronization, inter-node traffic.

The correct answers are B and C. Juniper Secure Connect uses route-based VPN connectivity, not policy-based VPN connectivity. Juniper’s Secure Connect user guide contrasts Dynamic VPN and Juniper Secure Connect and identifies Juniper Secure Connect as using route-based VPN connectivity, with a tunnel interface selected or created to bind the VPN. This is why SRX configurations for Juniper Secure Connect use an st0 tunnel interface and routing/security policy logic, rather than policy-based encryption tied directly to individual firewall policies.

Option B is also correct because Juniper Secure Connect can use a self-signed certificate. Juniper’s certificate deployment guidance states that before deploying Juniper Secure Connect, the SRX should use an appropriate certificate, which can be a signed certificate, a self-signed certificate, or a Let’s Encrypt-signed certificate. The documentation also shows generating a self-signed certificate and binding it to the SRX for Secure Connect use.

Option A is wrong because policy-based VPN describes older Dynamic VPN behavior, not Juniper Secure Connect. Option D is directly contradicted by Juniper’s certificate guidance. Reference topics: Juniper Secure Connect, route-based VPN, st0 tunnel interface, certificate deployment, self-signed certificate support.

The correct answer is D. exempt. In Junos IDP, the exempt rulebase is specifically used to prevent selected traffic from triggering known false-positive detections. Juniper’s IDP documentation explains that exempt rules can be configured when an IDP policy generates false positives for a particular attack object, source, destination, or traffic pattern. The exempt rulebase lets the administrator exclude matching traffic from attack detection while still allowing the rest of the IDP policy to inspect other traffic normally.

Option A, IPS, is wrong because the IPS rulebase is the main inspection rulebase used to detect and act on attacks. It is where attack objects and actions are commonly applied, but it is not the rulebase designed to eliminate false positives. Option B, monitor, is not the correct false-positive elimination mechanism. Monitoring can help observe behavior, but it does not exempt traffic from matching an attack object. Option C, signature, is wrong because signatures are attack-detection patterns, not a rulebase type used to suppress false positives. The operational correction for noisy or irrelevant matches is to create an exempt rule for the specific trusted source, destination, or attack object. Reference topics: IDP rulebases, exempt rulebase, false-positive tuning, attack objects, IPS inspection.

The correct answers are B and C. Juniper IDP uses attack objects as match conditions inside IDP policy rules. Juniper states that IDP attack objects represent known and unknown attacks and that the predefined attack object database is periodically updated by Juniper Networks. The main IDP attack object types include signature attack objects, protocol anomaly attack objects, and compound attack objects.

Option C is correct because signature attack objects detect known attacks using stateful attack signatures. Juniper defines a signature as a pattern that exists within a specific section of an attack and includes protocol, service, direction, flow, and context information to reduce false positives.

Option B is correct because protocol anomaly attack objects detect abnormal protocol behavior. Juniper explains that protocol anomaly objects identify unusual or ambiguous traffic that violates protocol specifications, RFCs, or common RFC extensions.

Option A is wrong because “statistic-based” is not one of the IDP attack object database types being tested here. Option D is wrong because “vector-based” is not a Juniper IDP attack object type. Reference topics: IDP, attack object database, signature-based attack objects, protocol anomaly attack objects, predefined attack objects.

The correct answer is D. AppQoS. The requirement is not to block, permit, translate, or inspect SIP signaling; it is to prioritize VoIP traffic on a low-bandwidth branch link. Juniper Application QoS, or AppQoS, is designed exactly for this purpose. Juniper states that AppQoS provides the ability to prioritize and meter application traffic so business-critical or high-priority application traffic receives better service. It can classify traffic by application, assign forwarding classes, rewrite DSCP values, set loss priority, and apply rate limiters.

Option A, AppFW, is wrong because AppFW controls application access; it is used to permit, deny, reject, or log application traffic, not primarily to prioritize voice traffic. Option B, SIP ALG, is wrong because the SIP ALG helps inspect and handle SIP control traffic and related media pinholes, but it is not a QoS prioritization service. Option C, AppQoE, is not the correct SRX edge service being tested here. For cloud-based VoIP under a broad outbound permit rule, AppQoS is the correct service because it can identify the VoIP application and give it better treatment during congestion. Reference topics: AppQoS, application traffic control, VoIP prioritization, DSCP rewrite, forwarding class, rate limiting.

The correct answer is B. Add custom-attack Custom-FTP-Attack to the attacks section and change the action to drop-packet. In the exhibit, the IDP rule is built under rulebase-ips with a match block and a then block. Attack objects belong inside the match attacks hierarchy because they define what malicious pattern the IDP rule is trying to detect. Juniper’s IDP documentation states that attack objects are specified in rules to identify malicious activity and that the rule’s attack objects/groups are the attacks the device matches in monitored traffic.

The enforcement behavior belongs in the then action hierarchy. The current rule uses close-client; to meet the requirement, it must be changed to drop-packet. Juniper defines Drop Packet as an IDP action that drops a matching packet before it reaches its destination without closing the connection. Option A keeps the wrong action. Option C is structurally wrong because a custom attack object is not configured under the action section. Option D is also wrong because the notification section controls logging/alert behavior, not attack matching. Reference topics: IDP rulebase, custom attack objects, match attacks hierarchy, IDP actions, drop-packet behavior.

The correct answers are A and B. In SRX chassis clustering, the fab interface is the fabric data-plane link between cluster nodes. Juniper explains that data-plane software synchronizes session state using runtime objects, or RTOs, across the fabric data link, and this fabric link also supports forwarding traffic between nodes when ingress and egress processing occur on different chassis members.

swfab is also a chassis-cluster data-plane-related interface used for Layer 2 switching fabric functionality. Juniper’s Ethernet switching on chassis cluster documentation describes swfab0 and swfab1 as pseudointerfaces created for Layer 2 fabric functionality, enabling switching across the nodes. Option C, fxp1, is wrong because fxp1 is the control link interface used for cluster control-plane communication, heartbeats, and synchronization signaling, not a data-plane fabric interface. Option D, fxp0, is wrong because fxp0 is the out-of-band management interface. The clean separation is: fxp0 = management, fxp1 = control link, fab = routed/data fabric, and swfab = Layer 2 switching fabric. Reference topics: HA Clustering, fab interfaces, swfab interfaces, control link, management interface, data-plane synchronization.

The correct answer is C. Enable connectivity between the SRX Series device and Juniper ATP Cloud. Juniper ATP Cloud cannot inspect files, receive verdicts, or apply cloud-based malware intelligence until the SRX is enrolled and has a working secure connection to the ATP Cloud service. Juniper states that SRX enrollment establishes a secure connection between the SRX Series Firewall and the Juniper ATP Cloud server, downloads and installs certificate authorities, creates local certificates, enrolls them with the cloud server, and establishes the secure cloud connection.

Option A is not the first required configuration setting because the anti-malware service depends on successful cloud onboarding and connectivity. Option B is premature because firewall/security policies can reference malware inspection only after the device is properly connected and enrolled. Option D is also later in the workflow; anti-malware policies define how files are inspected and what action is taken, but those policies are useless if the SRX cannot communicate with ATP Cloud. Juniper also notes that ATP Cloud requires both the Routing Engine and Packet Forwarding Engine to reach the Internet, and DNS must resolve the cloud URL. Reference topics: ATP Cloud onboarding, SRX enrollment, advanced anti-malware connection, secure cloud connectivity, anti-malware policy deployment.

The correct answers are A and D. In IKEv1-based IPsec VPNs, there are two distinct negotiation phases. IKEv1 Phase 1 establishes the secure and authenticated IKE channel between peers. That means the IKE SA is built during Phase 1. Juniper describes Phase 1 as the negotiation of proposals for how to authenticate and secure the channel, including encryption algorithms, authentication algorithms, Diffie-Hellman group, and authentication method.

IKEv1 Phase 2 then uses that secure channel to negotiate the IPsec SAs that protect actual user traffic through the VPN. Juniper states that Phase 2 negotiates security associations to secure the data traversing the IPsec tunnel, and that the Phase 2 proposal includes the security protocol, such as ESP or AH, plus the selected encryption and authentication algorithms. Option B is wrong because IKEv1 SAs are not established in Phase 2; Phase 2 creates IPsec SAs. Option C is wrong because Phase 1 does not create the data-plane IPsec SA; it creates the secure IKE control channel used for Phase 2 negotiation. Reference topics: IPsec VPN, IKEv1 Phase 1, IKE SA, IKEv1 Phase 2, IPsec SA, ESP/AH proposals.
