Install the Runtime Class for gVisor

{ # Step 1: Install a RuntimeClass

cat <

apiVersion: node.k8s.io/v1beta1

kind: RuntimeClass

metadata:

name: gvisor

handler: runsc

EOF

}

Create a Pod with the gVisor Runtime Class

{ # Step 2: Create a pod

cat <

apiVersion: v1

kind: Pod

metadata:

name: nginx-gvisor

spec:

runtimeClassName: gvisor

containers:

- name: nginx

image: nginx

EOF

}

Verify that the Pod is running

{ # Step 3: Get the pod

kubectl get pod nginx-gvisor -o wide

}

Kubernetes auditing provides a security-relevant chronological set of records about a cluster. Kube-apiserver performs auditing. Each request on each stage of its execution generates an event, which is then pre-processed according to a certain policy and written to a backend. The policy determines what’s recorded and the backends persist the records.

You might want to configure the audit log as part of compliance with the CIS (Center for Internet Security) Kubernetes Benchmark controls.

The audit log can be enabled by default using the following configuration in cluster.yml:

services:

kube-api:

audit_log:

enabled: true

When the audit log is enabled, you should be able to see the default values at /etc/kubernetes/audit-policy.yaml

The log backend writes audit events to a file in JSONlines format. You can configure the log audit backend using the following kube-apiserver flags:

--audit-log-path specifies the log file path that log backend uses to write audit events. Not specifying this flag disables log backend. - means standard out

--audit-log-maxage defined the maximum number of days to retain old audit log files

--audit-log-maxbackup defines the maximum number of audit log files to retain

--audit-log-maxsize defines the maximum size in megabytes of the audit log file before it gets rotated

If your cluster's control plane runs the kube-apiserver as a Pod, remember to mount the hostPath to the location of the policy file and log file, so that audit records are persisted. For example:

--audit-policy-file=/etc/kubernetes/audit-policy.yaml \

--audit-log-path=/var/log/audit.log

apiVersion: policy/v1beta1

kind: PodSecurityPolicy

metadata:

name: restricted

annotations:

seccomp.security.alpha.kubernetes.io/allowedProfileNames: 'docker/default,runtime/default'

apparmor.security.beta.kubernetes.io/allowedProfileNames: 'runtime/default'

seccomp.security.alpha.kubernetes.io/defaultProfileName: 'runtime/default'

apparmor.security.beta.kubernetes.io/defaultProfileName: 'runtime/default'

spec:

privileged: false

# Required to prevent escalations to root.

allowPrivilegeEscalation: false

# This is redundant with non-root + disallow privilege escalation,

# but we can provide it for defense in depth.

requiredDropCapabilities:

- ALL

# Allow core volume types.

volumes:

- 'configMap'

- 'emptyDir'

- 'projected'

- 'secret'

- 'downwardAPI'

# Assume that persistentVolumes set up by the cluster admin are safe to use.

- 'persistentVolumeClaim'

hostNetwork: false

hostIPC: false

hostPID: false

runAsUser:

# Require the container to run without root privileges.

rule: 'MustRunAsNonRoot'

seLinux:

# This policy assumes the nodes are using AppArmor rather than SELinux.

rule: 'RunAsAny'

supplementalGroups:

rule: 'MustRunAs'

ranges:

# Forbid adding the root group.

- min: 1

max: 65535

fsGroup:

rule: 'MustRunAs'

ranges:

# Forbid adding the root group.

- min: 1

max: 65535

readOnlyRootFilesystem: false

You can create a "default" isolation policy for a namespace by creating a NetworkPolicy that selects all pods but does not allow any ingress traffic to those pods.

---

apiVersion: networking.k8s.io/v1

kind: NetworkPolicy

metadata:

name: default-deny-ingress

spec:

podSelector: {}

policyTypes:

- Ingress

You can create a "default" egress isolation policy for a namespace by creating a NetworkPolicy that selects all pods but does not allow any egress traffic from those pods.

---

apiVersion: networking.k8s.io/v1

kind: NetworkPolicy

metadata:

name: allow-all-egress

spec:

podSelector: {}

egress:

- {}

policyTypes:

- Egress

Default deny all ingress and all egress trafficYou can create a "default" policy for a namespace which prevents all ingress AND egress traffic by creating the following NetworkPolicy in that namespace.

---

apiVersion: networking.k8s.io/v1

kind: NetworkPolicy

metadata:

name: default-deny-all

spec:

podSelector: {}

policyTypes:

- Ingress

- Egress

This ensures that even pods that aren't selected by any other NetworkPolicy will not be allowed ingress or egress traffic.

Text Description automatically generated

Text Description automatically generated

Text Description automatically generated

[desk@cli] $ k create sa backend-qa -n qasa/backend-qa created[desk@cli] $ k get role,rolebinding -n qaNo resources found in qa namespace.[desk@cli] $ k create role backend -n qa --resource pods,namespaces,configmaps --verb list# No access to secret[desk@cli] $ k create rolebinding backend -n qa --role backend --serviceaccount qa:backend-qa[desk@cli] $ vim /home/cert_masters/frontend-pod.yaml

apiVersion: v1

kind: Pod

metadata:

 name: frontend

spec:

 serviceAccountName: backend-qa # Add this

  image: nginx

  name: frontend

[desk@cli] $ k apply -f /home/cert_masters/frontend-pod.yamlpod created

[desk@cli] $ k create sa backend-qa -n qaserviceaccount/backend-qa created[desk@cli] $ k get role,rolebinding -n qaNo resources found in qa namespace.[desk@cli] $ k create role backend -n qa --resource pods,namespaces,configmaps --verb listrole.rbac.authorization.k8s.io/backend created[desk@cli] $ k create rolebinding backend -n qa --role backend --serviceaccount qa:backend-qarolebinding.rbac.authorization.k8s.io/backend created[desk@cli] $ vim /home/cert_masters/frontend-pod.yaml

apiVersion: v1

kind: Pod

metadata:

 name: frontend

spec:

 serviceAccountName: backend-qa # Add this

  image: nginx

  name: frontend

[desk@cli] $ k apply -f /home/cert_masters/frontend-pod.yamlpod/frontend createdhttps://kubernetes.io/docs/tasks/configure-pod-container/configure-service-account/

Fix all of the following violations that were found against the API server:-

 a. Ensure that the RotateKubeletServerCertificate argument is set to true.

apiVersion: v1

kind: Pod

metadata:

creationTimestamp: null

labels:

component: kubelet

tier: control-plane

name: kubelet

namespace: kube-system

spec:

containers:

- command:

- kube-controller-manager

+ - --feature-gates=RotateKubeletServerCertificate=true

image: gcr.io/google_containers/kubelet-amd64:v1.6.0

livenessProbe:

failureThreshold: 8

httpGet:

host: 127.0.0.1

path: /healthz

port: 6443

scheme: HTTPS

initialDelaySeconds: 15

timeoutSeconds: 15

name: kubelet

resources:

requests:

cpu: 250m

volumeMounts:

- mountPath: /etc/kubernetes/

name: k8s

readOnly: true

- mountPath: /etc/ssl/certs

name: certs

- mountPath: /etc/pki

name: pki

hostNetwork: true

volumes:

- hostPath:

path: /etc/kubernetes

name: k8s

- hostPath:

path: /etc/ssl/certs

name: certs

- hostPath:

path: /etc/pki

name: pki

  b. Ensure that the admission control plugin PodSecurityPolicy is set.

audit: "/bin/ps -ef | grep $apiserverbin | grep -v grep"

tests:

test_items:

- flag: "--enable-admission-plugins"

compare:

op: has

value: "PodSecurityPolicy"

set: true

remediation: |

Follow the documentation and create Pod Security Policy objects as per your environment.

Then, edit the API server pod specification file $apiserverconf

on the master node and set the --enable-admission-plugins parameter to a

value that includes PodSecurityPolicy :

--enable-admission-plugins=...,PodSecurityPolicy,...

Then restart the API Server.

scored: true

c. Ensure that the --kubelet-certificate-authority argument is set as appropriate.

audit: "/bin/ps -ef | grep $apiserverbin | grep -v grep"

tests:

test_items:

- flag: "--kubelet-certificate-authority"

set: true

remediation: |

Follow the Kubernetes documentation and setup the TLS connection between the

apiserver and kubelets. Then, edit the API server pod specification file

$apiserverconf on the master node and set the --kubelet-certificate-authority

parameter to the path to the cert file for the certificate authority.

--kubelet-certificate-authority=

scored: true

Fix all of the following violations that were found against the ETCD:-

a. Ensure that the --auto-tls argument is not set to true

Edit the etcd pod specification file $etcdconf on the masternode and either remove the --auto-tls parameter or set it to false.--auto-tls=false

b. Ensure that the --peer-auto-tls argument is not set to true

Edit the etcd pod specification file $etcdconf on the masternode and either remove the --peer-auto-tls parameter or set it to false.--peer-auto-tls=false
