Root protection ensures that a designated port does not become a root port by discarding superior BPDUs. However, if superior BPDUs are no longer received, the port can return to its original forwarding state, meaning its role can change. This makes option B incorrect, while the other options correctly describe RSTP behavior ​.

1 → A Startup message with a priority of 255 is received.

2 → A Startup message with a priority less than 255 is received.

3 → A Shutdown message is received.

4 → The Master_Down timer expires, an Advertisement packet with the priority of 0 is received, or a packet with a priority lower than the local priority is received.

5 → A packet with a priority higher than the local priority is received.

6 → A Shutdown message is received.

???? Reference: Huawei HCIA-Datacom Study Guide, VRRP Status Transitions.

The command output indicates that the OSPF neighbor state is Full and that the neighbor relationship has been established. The statement confirms that the negotiation process during the exchange of DD (Database Description) packets has determined the role of the router, with the local device becoming the slave in the Master-Slave relationship, which is critical for LSA synchronization. The other options do not align with the output or OSPF principles ​

Comprehensive and Detailed in-depth Step-by-Step Explanation:

In IS-IS, the interface cost is a metric used to determine the best path to a destination. Lower-cost paths are preferred over higher-cost paths. By default, IS-IS interface costs can range from 1 to 63 .

Default Cost Range:

IS-IS allows the configuration of interface costs within the range of 1–63 by default. This range is sufficient for most networks.

Maximum Configurable Cost:

The maximum value that can be configured by default is 63 . If there is a requirement for a higher cost range, the metric-style can be changed to wide , which allows the cost range to extend beyond 63.

Option A (67): Incorrect. 67 is not the maximum default value.

Option B (63): Correct. This is the maximum default cost value.

Option C (64): Incorrect. This is beyond the default range.

Option D (68): Incorrect. This is beyond the default range.

Secure access channels include protocols that encrypt the transmitted data to protect against interception or unauthorized access. HTTPS (HyperText Transfer Protocol Secure) ensures data encryption over web communications, while SFTP (Secure File Transfer Protocol) provides secure file transfer by utilizing SSH for data encryption. Telnet and SNMPv2, on the other hand, lack robust encryption and are considered insecure. Huawei security standards highlight the importance of encrypted communication to prevent data leaks ​.

Comprehensive and Detailed Step-by-Step Explanation:

Bidirectional Forwarding Detection (BFD):

BFD is a lightweight protocol that provides rapid fault detection on links independent of the underlying routing protocol or media.

Requirements for BFD:

Both devices at the endpoints of the link must support and configure BFD for it to operate.

If one device does not support BFD, the feature cannot be used for link detection.

In VRRP HSB (Hot Standby Backup) mode for WLAN deployments (typically between ACs or access controllers), backup of critical data ensures fast failover and minimal service disruption.

A. Real-time backup – Supported. Configuration and session information are synchronized in real-time between the active and standby ACs.

B. Scheduled synchronization – Not supported . HSB requires instant synchronization, not based on a scheduled time.

C. Batch backup – Supported. Some types of less time-sensitive data (e.g., logs or counters) may be backed up in batches.

D. Cloud backup – Not part of HSB functionality . Cloud backup is a separate mechanism, typically used for archival purposes, not real-time failover.

Reference from Huawei HCIP-Datacom-Core Technology Study Guide:

“VRRP HSB mode supports real-time and batch backup between ACs to protect WLAN services. Scheduled and cloud backups are not part of HSB functionality.”

(Chapter: WLAN Reliability – Section: AC Redundancy and HSB Mechanism)
