Based on the FortiOS 7.6 Infrastructure and IPsec VPN documentation, Dead Peer Detection (DPD) can be configured in three primary modes: On Demand, On Idle, and Disabled.

On Demand (Default Mode): This mode is specifically designed to minimize unnecessary traffic. In this mode, FortiGate sends DPD probes only when there is no inbound traffic but the FortiGate is attempting to send outbound traffic. Because network communication is typically bidirectional, the absence of inbound traffic while outbound traffic is being sent is a primary indicator of a potentially dead tunnel. This matches the specific requirement described in the question.

On Idle: In this mode, DPD probes are sent if no traffic (neither inbound nor outbound) has been observed in the tunnel for a specific period. It verifies the tunnel status even when the connection is completely idle.

Enabled: In older versions or specific CLI contexts, " Enabled " may refer to periodic DPD, but in the current FortiOS 7.x/7.6 GUI and CLI terminology for Phase 1 settings, the active modes are defined as on-demand or on-idle.

Disabled: In this mode, the FortiGate does not send DPD probes but will still respond to DPD probes sent by the remote peer.

The requirement that the administrator wants probes sent only when there is no inbound traffic (usually implying the FortiGate is sending but not receiving) is the fundamental definition of the On Demand mechanism in the Fortinet curriculum.

In FortiOS 7.6, web filter profiles are inspection-mode dependent. Certain advanced web filtering features—such as daily category usage quota—are only supported when the firewall policy is operating in proxy-based inspection mode.

Why the profile is not visible

The profile restrictmedia-profile includes a daily category usage quota.

Daily quotas are a proxy-based web filtering feature.

If the firewall policy is configured with:

Inspection mode: Flow-based

Then FortiGate will not display proxy-only web filter profiles in the Web Filter drop-down list.

FortiGate automatically filters the available profiles based on feature compatibility with the policy’s inspection mode.

This behavior is explicitly documented in the FortiOS 7.6 Web Filtering and Inspection Mode Compatibility sections.

Why the other options are incorrect

A. Already referenced in another firewall policyWeb filter profiles can be reused across multiple policies. This does not hide them.

B. Firewall policy is in no-inspection mode instead of deep-inspectionSSL inspection depth affects HTTPS visibility, not whether a web filter profile appears in the drop-down list.

C. Naming convention restrictionFortiOS does not restrict profile selection based on naming conventions.

“As previously stated, collector agent-based polling mode has three methods (or options) for collecting login information. The order on the slide from left to right shows most recommend to least recommended:

• WMI ...

• WinSecLog ...

• NetAPI ...”

Technical Deep Dive:

The correct three AD polling methods are WMI, WinSecLog, and NetAPI . These are the collector-agent polling options FortiGate FSSO uses against Windows domain controllers. WMI is generally the most efficient because the DC returns requested login events directly. WinSecLog polls Windows Security Event Logs and is typically more reliable than NetAPI for not missing recorded logons. NetAPI can be faster, but it is more prone to missing events under load because it depends on temporary session information rather than persistent security logs.

Why the other options are wrong:

DNS reverse lookup is not one of the three AD polling methods. DNS is used by FSSO to resolve workstation names to IP addresses and to track IP changes, but it is not itself a polling method for collecting AD logon events. FSSO REST API is also not one of the documented collector-agent AD polling methods in the study guide.

From an operational standpoint, FSSO login collection and workstation verification are separate functions. The collector agent may still rely on DNS and workstation checks after a login is learned, but the actual AD polling methods remain only WMI, WinSecLog, and NetAPI . On a FortiGate, when troubleshooting FSSO behavior, you would typically validate the collector feed and user cache with commands such as:

diagnose debug authd fsso list

diagnose debug authd fsso server-status

Those commands help confirm whether the users gathered by the collector through one of those three polling methods are reaching FortiGate correctly.

In FortiOS 7.6, when multiple dialup IPsec VPNs are configured on the same FortiGate—especially in Aggressive Mode—FortiGate must identify which Phase 1 configuration a connecting client should match.

How FortiGate selects a dialup IPsec tunnel

For dialup VPNs:

The remote peer (user or device) does not have a fixed IP address

Multiple Phase 1 interfaces may exist on the HQ FortiGate

FortiGate uses identifying information sent during IKE Phase 1 to select the correct tunnel

Aggressive Mode behavior

Aggressive mode sends ID information in clear text during Phase 1

This allows FortiGate to match incoming peers to the correct Phase 1 configuration

Why Peer ID is the correct answer

C. Peer ID

Peer ID (also called IKE ID) is used to:

Identify the remote peer

Differentiate between multiple dialup tunnels

Common Peer ID formats:

FQDN

User FQDN

Key ID

FortiGate matches the received Peer ID against the Phase 1 configuration to select the correct tunnel

This is the documented and recommended method for:

Mapping users to different department tunnels

Supporting multiple dialup IPsec VPNs in aggressive mode

Why the other options are incorrect

A. Local GatewayIdentifies the local FortiGate interface/IP, not the remote user.

B. Dead Peer DetectionUsed only for tunnel health monitoring, not tunnel selection.

D. IKE Mode ConfigUsed for assigning IP addresses and pushing settings, not for selecting the Phase 1 tunnel.

In FortiSASE Secure Internet Access (SIA) agent-based mode, traffic steering and security enforcement rely on components integrated with the FortiClient agent.

Components used in SIA agent-based mode

A. FortiSASE Firewall-as-a-Service (FWaaS)

Correct.

FWaaS is a core security component of FortiSASE.

It enforces firewall policies, security inspection, and access control for agent-based users.

All user traffic tunneled by the agent is inspected by FWaaS.

C. VPN policies

Correct.

In agent-based mode, the FortiClient establishes a secure tunnel to FortiSASE.

VPN policies define:

Authentication

Access control

Traffic steering

These policies are fundamental to agent-based connectivity.

Why the other options are incorrect

B. Proxy auto-configuration (PAC) filePAC files are used in agentless or proxy-based modes, not agent-based SIA.

D. FortiExtenderFortiExtender is a WAN extension device and is unrelated to FortiSASE SIA agent-based architecture.

According to the FortiOS 7.6 Administration Guide and Security Fabric documentation, automation stitches are designed to automate responses to security and system events across the network. A core characteristic of these stitches is their flexibility in action execution; specifically, multiple actions can run in parallel (Statement C). While the system allows for sequential execution with configurable delays between actions, the default behavior or configuration option allows for simultaneous responses, such as sending an email notification while simultaneously triggering a webhook or quarantining a host.

Furthermore, triggers can involve external connectors (Statement D). While many triggers are local to the FortiGate (such as reboots or log events), the Security Fabric allows the FortiGate to monitor and react to events from external components like FortiAnalyzer , FortiSIEM , or FortiClient EMS . For example, a FortiAnalyzer event handler can act as the trigger for a stitch on the root FortiGate. Statement A is incorrect because actions can target external systems like AWS Lambda or Slack which are not internal Fabric devices. Statement B is incorrect because each automation stitch is typically defined by a single trigger , though that trigger itself can be broad (e.g., " Any Security Rating Notification " ).

Based on the FortiOS 7.6 Administrator Guide regarding Fortinet Single Sign-On (FSSO) polling modes, the agentless polling mode has specific technical characteristics:

SMB Protocol Usage (Statement B is True):

In agentless polling mode, the FortiGate unit itself acts as the collector.

It establishes direct connections to the Windows Domain Controllers (DCs) using the SMB (Server Message Block) protocol, typically over TCP port 445, to read the Windows Security Event logs.

This allows FortiGate to parse login event IDs (such as 4768 and 4769) to identify users and their corresponding IP addresses without needing an external collector agent installed on a server.

Workstation Check Support (Statement C is True):

One of the primary limitations of the agentless polling mode compared to the agent-based mode is the lack of workstation verification.

In agentless mode, FortiGate does not perform " workstation checks " or " dead entry checks " . This means it cannot proactively verify if a user is still logged into a specific workstation after the initial logon event is recorded, which can lead to stale entries if a user logs off without a corresponding event being captured.

Why other options are incorrect:

Option A: In agentless mode, FortiGate (the FSSO daemon) performs the collection itself; it does not use the AD server as a " collector agent " in the functional sense of FSSO architecture.

Option D: While FortiGate uses LDAP to retrieve group membership information once a user is identified, it does not " direct " a collector agent to a remote LDAP server, as there is no external collector agent involved in this specific mode.

“In this use case, FortiSASE acts as an SWG and distributes a proxy auto-configuration (PAC) file to end users, enabling the FortiSASE SWG service as an explicit web proxy. SWG deployment secures only web traffic protocols, such as HTTP and HTTPS.”

“All other nonweb traffic bypasses FortiSASE and is forwarded directly to the internet.”

Technical Deep Dive:

The correct answer is A .

In agentless SWG-based SIA , FortiSASE is operating as an explicit web proxy using a PAC file . That model captures only web protocols , specifically HTTP and HTTPS . It does not create a full tunnel for the endpoint like agent-based FortiClient deployment does.

So the design implication is simple: nonweb traffic does not traverse FortiSASE in this onboarding model. It goes directly to the internet from the endpoint.

Why the other options are wrong:

B is wrong because this is not split-tunnel VPN behavior.

C is wrong because FWaaS does not automatically capture nonweb traffic in the agentless SWG model.

D is wrong because SWG does not redirect nonweb traffic to FortiExtender.

This is an important deployment distinction:

Agent-based SIA can steer broader endpoint traffic through FortiSASE.

Agentless SWG SIA secures only browser-based web traffic.

“This slide shows the SD-WAN rule lookup process. SD-WAN rules are essentially policy routes.”

“FortiGate performs a forwarding information base (FIB) lookup for the packet destination IP (dstip). If the resolved interface for the fib-best-match isn’t an SD-WAN member, then FortiGate moves on to the next rule. This behavior follows the key routing principle: SD-WAN rules are skipped if the best route to the destination isn’t an SD-WAN member .”

“If the resolved interface is an SD-WAN member, then FortiGate looks for one or more acceptable members in the oif list... An acceptable member is an alive member that has a route to the destination. This behavior follows the key routing principle: SD-WAN rules are skipped if none of the configured members in the rule have a valid route to the destination .”

“Because regular policy routes have precedence over any other routes...”

“Also note that policy routes have precedence over SD-WAN rules, and over any routes in the FIB.”

Technical Deep Dive:

The correct answers are A, C, and E .

A is correct because an SD-WAN rule is not enough by itself. A selected member must also be alive and have a valid route to the destination. If none of the members referenced by the rule can actually reach the destination, the rule is skipped.

C is correct because a regular policy route is evaluated before SD-WAN rules. This is a classic exam trap. FortiGate treats SD-WAN steering like policy-route logic, but standard policy routes still win if they match and are valid.

E is correct because FortiGate first checks the FIB best match . If that best route resolves to an interface that is not an SD-WAN member, FortiGate skips the SD-WAN rule and continues.

Why the others are wrong:

B is false because SD-WAN rules do not have precedence over everything; regular policy routes do.

D is false because the number of available routes is not the deciding rule. Even with only one route, SD-WAN can still steer traffic if the routing and member conditions are met.

Operationally, think of SD-WAN routing in this order: policy route check → SD-WAN rule lookup → standard FIB fallback . On FortiGate, the practical validation commands are:

get router info routing-table all

diagnose sys sdwan service

diagnose firewall proute list

That combination lets you confirm whether a packet is being captured by a policy route, whether an SD-WAN rule has acceptable members, and what the FIB currently resolves for the destination.
