Step 1: Create an instance of Azure Application Insights

1. Open Microsoft Azure Portal

2. Log into your Azure account, Select Create a resource > Developer tools > Application Insights.

3. Enter the followingsettings, and then select Review + create.

Name: az400-9940427-main

Step 2: Configure App Insights SDK

1. Open your ASP.NET Core Web App project in Visual Studio > Right-click on the AppName in the Solution Explorer > Select Add > Application InsightsTelemetry.

2. Click the Get Started button

3. Select your account and subscription > Select the Existing resource you created in the Azure portal > Click Register.

To ensure that your Azure Web App namedaz400-38443478-mainsupports rolling upgrades and only 10 percent of users connect to the updated version of the app, you can use deployment slots with the followingsteps:

Create a Deployment Slot:

Navigate to the Azure Portal.

Go to your Web Appaz400-38443478-main.

SelectDeployment slotsin the menu.

Click onAdd Slot.

Name the slot (e.g.,staging) and if needed, clone settings from the production slot.

Configure the Traffic Percentage:

In the Deployment Slots menu, you will see a column forTraffic %.

Set the traffic percentage to10%for thestagingslot1.

This will route only 10% of the traffic to the updated version of the app in thestagingslot.

Deploy the Updated App to the Staging Slot:

Deploy yourupdated application to thestagingslot.

Test the application in thestagingslot to ensure it’s working as expected.

Complete the Rolling Upgrade:

Once you’re satisfied with the performance and stability of the app in thestagingslot, you can graduallyincrease the percentage of traffic until you’re ready to swap with the production slot.

To swap slots, go to theDeployment slotsmenu and click onSwapwith the production slot.

By using deployment slots, you can achieve rolling upgrades with minimal administrative effort, as it allows you to test the new version on a subset of users before fully releasing it. Remember to adjust the traffic percentage and monitor the application’s performance throughout the process.

Task 7: Create a Pipeline to Deploy a Docker Image in a New Branch

Step 1: Create a New Branch

In your Azure DevOps Project (Project1), navigate to Repos .

In the left menu, click on Branches .

Click New branch .

Enter:

Branch name: azure-pipelines

Based on: main (or your default branch)

Click Create .

This creates a new branch named azure-pipelines.

Step 2: Switch to the New Branch

In Repos , click on Files .

In the top-left branch selector, choose azure-pipelines .

Step 3: Use the Predefined Docker Pipeline Template

Azure Pipelines has predefined YAML templates for common tasks, including Docker.

Here’s how to add it:

In the azure-pipelines branch, click New file .

Name the file: azure-pipelines.yml.

Click the Show templates button in the YAML editor (if available).

Search for the Docker template in the list of predefined templates.

Select the Docker template to auto-populate the YAML file.

If the editor doesn’t show the template picker, you can manually add the following basic Docker pipeline template:

yaml

Copy

# Predefined Docker pipeline template

trigger:

- main

resources:

- repo: self

variables:

imageName: ' mydockerimage '

stages:

- stage: Build

displayName: Build and push stage

jobs:

- job: Build

pool:

vmImage: ' ubuntu-latest '

steps:

- task: Docker@2

displayName: Build and push an image to container registry

inputs:

command: buildAndPush

repository: $(imageName)

dockerfile: ' **/Dockerfile '

containerRegistry: ' < your-container-registry-service-connection > '

tags: |

latest

Replace < your-container-registry-service-connection > with your actual Azure Container Registry (ACR) or DockerHub service connection name.

Step 4: Commit the Pipeline to the New Branch

In the YAML editor, review and adjust if needed (like setting the correct container registry service connection).

In the bottom commit message box:

Message: e.g., Add Docker deployment pipeline

Ensure the branch is set to azure-pipelines .

Click Commit (not commit to main).

This creates the pipeline YAML file in the new azure-pipelines branch.

Step 5: Create the Pipeline in Azure DevOps

In the left menu, click Pipelines .

Click New pipeline .

Choose:

Azure Repos Git .

Select your repo.

Select Existing Azure Pipelines YAML file .

In the branch selector, choose the azure-pipelines branch.

Select the YAML file path (azure-pipelines.yml).

Click Continue and then Run to validate the pipeline.

Step1: Create a New Team Dashboard

Navigate to Azure DevOps:

Go to Azure DevOps and sign in with your credentials.

Select Your Project:

Choose Project1 from your list of projects.

Access Dashboards:

In the left-hand menu, select Dashboards.

Create a New Dashboard:

Click on New Dashboard.

Enter the name Dashboard1.

Ensure the dashboard type is set to Team Dashboard.

Click Create.

Step 2: Add the Team Members Widget

Open the Widget Catalog:

After creating the dashboard, thewidget catalog will open automatically. If it doesn’t, click on Add Widget.

Search for Team Members Widget:

In the widget catalog, search for Team Members.

Add the Widget:

Click on the Team Members widget and then click Add to place it on your dashboard.

Configure the Widget:

Once added, you can resize and move the widget to your preferred location on the dashboard.

Step 3: Save and Share the Dashboard

Save the Dashboard:

Click on Save to save your changes.

Share the Dashboard:

You can share the dashboardURL with your team members or set permissions to control who can view or edit the dashboard.

By following these steps, you will have a new team dashboard named Dashboard1 that displays the members of the default project team for Project1

Set up staging environments in Azure App Service

1. Open Microsoft Azure Portal

2. Log into your Azure account, select your app ' s resource page, in the left pane, selectDeployment slots > Add Slot.

3. In the Add a slot dialog box, give the slot a name, and select whether to clone an app configuration from another deployment slot. Select Add to continue.

4. After the slot is added, select Close to close the dialogbox. The new slot is now shown on the Deployment slots page. By default, Traffic % is set to 0 for the new slot, with all customer traffic routed to the production slot.

5. Select the new deployment slot to open that slot ' s resource page.

6. Change TRAFFIC % to 10

Task 12: Configure Iterations in Project1 for Azure Boards

Step 1: Navigate to Project Settings

In your Azure DevOps Project (Project1), click on the Project settings gear icon in the lower-left corner.

Step 2: Manage Project Iterations (Sprints)

In the Boards section of the Project settings, click Project configuration .

In the left menu, click on Iterations .

Step 3: Add Iterations

Click on the + New child link to add a new iteration under the root node (e.g., Project1).

Enter the following details:

Name: Sprint 1

Leave the start and end dates empty (or set them as needed for your planning).

Click Save and close .

Repeat the process:

Click + New child again.

Name: Sprint 2

Leave the start and end dates empty.

Click Save and close .

Finally, create Sprint 3 with specific dates:

Click + New child .

Name: Sprint 3

Start date: January 1 of next year (e.g., 2026-01-01).

End date: January 31 of next year (e.g., 2026-01-31).

Click Save and close .

Step 4: Assign Iterations to Work Items

With these iterations created, you can now assign them to work items (e.g., tasks, bugs, features) using Azure Boards.

In Boards , click on Work items .

Open any work item.

In the Iteration Path field, select one of your newly created iterations (Sprint 1, Sprint 2, or Sprint 3).

This ensures that work items can be tracked under the appropriate sprint.

anation:

1. In the Azure portal, navigate to the az400-9940427-main app ' s management page. In the app ' s left menu, click Configuration > Application settings.

2. Click New Application settings

3. Enter the following:

Name: MAX_ITEMS

Value: 50
