The ICC opening-location rule requires intake openings to be located not less than 10 feet from lot lines or buildings on the same lot . A combustion-air opening taken from the exterior follows that minimum separation rule, so 10 feet is the correct answer. Therefore, Option D is correct.

ICC mechanical access provisions for appliances in attics require the passageway to be not more than 20 feet in length , measured along the centerline of the passageway from the opening to the appliance, where the attic passageway is the standard reduced-height access condition. Since the attic height given is 66 inches, the standard maximum length applies, so Option C is correct. The 50-foot allowance applies only under a different exception where the passageway is unobstructed and at least 6 feet high for its entire length.

Under the ICC administrative provisions used with the mechanical code, one approved set is retained by the code official, and one approved set is returned to the applicant. The returned set must be kept on the site of the building or job while the authorized work is in progress. That directly matches Option A . It does not require return to the architect, filing with the county clerk, or retention for one year after completion.

Based on the mechanical plan shown in the exhibit, the gas line between unit heaters 5 and 8 is labeled as 1 inch in diameter. Therefore, the correct answer is B.

The ICC mechanical code provision for infrared radiant heaters states that the heaters must be installed with clearances from combustible material in accordance with the manufacturer’s installation instructions . That makes Option D the correct answer. The code does not establish a blanket 6-foot clearance on all sides in this section, and the exam expects the candidate to rely on the listed installation requirements for the appliance.

The IMC requires clothes dryer exhaust ducts to terminate outside the building and to be equipped with a backdraft damper at the terminal. The code also prohibits screens at dryer terminations because lint can accumulate and obstruct flow. That makes Option A correct and eliminates Option C . The other two choices describe controls not required by the dryer exhaust termination rule.

For mechanical draft venting systems, unless the appliance is listed for a different clearance, the vent terminal must be located not less than 4 feet below , 4 feet horizontally from , or 1 foot above any door, operable window, or gravity air inlet into a building. Therefore, the required minimum distance below an openable window is 4 feet , so Option B is correct.

The ICC administrative provisions require construction documents to be submitted in two or more sets with the permit application. After approval, one set is retained by the code official and one set is returned to the applicant to be kept on the job site during construction. That is exactly the condition described in Option D . The code does not state that all sets are retained by the code official or that the purpose is to provide subcontractor copies or backup copies.

The applicable provision requires direct-fired industrial air heaters to supply outside ventilation air at a rate of not less than 4 cfm per 1,000 Btu/h of rated input where ventilation air is provided by separate mechanical means. For 200,000 Btu/h , the required outside air is:

200,000 ÷ 1,000 = 200

200 × 4 = 800 cfm

So the correct answer is C

This question appears to contain a wording issue. In ICC flood-related provisions tied to ventilation/flood openings, the governing limit is that the opening location is not more than 1 foot relative to the reference grade condition used for flood-opening compliance. That corresponds to 1 foot , so Option C is the best-supported answer.
