The OfficeExtend Access Point (OEAP) split tunnel feature allows the separation of corporate and local traffic. By implementing a split tunnel, remote workers can maintain wireless connectivity to the corporate network while simultaneously accessing local network resources such as printers. This solution ensures that local traffic does not have to traverse the corporate network, which can cause connectivity issues like the ones reported by the users. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide

The correct URL to be used in the configuration as the external redirection URL for guests to view the company’s Facebook page before accessing the network is http:// :8083/fbwifi/forward (B). This URL is associated with the Cisco MSE’s Facebook Wi-Fi feature, which facilitates the redirection process. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide.

Cisco Prime Infrastructure reporting provides a comprehensive summary of inconsistencies and missed best practices related to WLAN controllers. It aggregates data from all WLCs, Cisco MSE, and itself to generate detailed reports. References: Cisco Prime Infrastructure reporting features documentation.

 Bluetooth Low Energy (BLE) is renowned for its ability to provide precise location services, especially in the context of indoor positioning systems. BLE beacons can be strategically placed throughout a facility, and when used in conjunction with a mobile application, they can deliver the high level of location accuracy required for various use cases, including navigation, asset tracking, and contextual marketing.

The image provided shows a packet capture with multiple entries displaying UDP traffic between two IP addresses using different ports (notably port number ‘16666’ which is commonly used for NMSP). Network Mobility Services Protocol (NMSP) is used by wireless controllers like WLCs to communicate with management software such as Cisco’s Mobility Services Engine or CMX. This protocol helps in managing various mobility services across wireless networks. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide

When deploying Cisco Hyperlocation, it is important to enable the feature on both the wireless LAN controller and Cisco CMX to ensure proper functionality and data accuracy. Additionally, if the Cisco CMX server is a VM, a high-end VM is required to handle the processing demands of Cisco Hyperlocation deployments. References: The considerations for deploying Cisco Hyperlocation are covered in the certification guide, which emphasizes the importance of enabling the feature on both the controller and CMX, as well as the hardware requirements for the CMX server.

To integrate the Mobility Services Engine (MSE) with Cisco Prime Infrastructure for tracking the location of clients and rogues on maps, it is essential to add the MSE to Cisco Prime Infrastructure using the communication credentials specific to Cisco Prime Infrastructure. This ensures that both systems can communicate effectively. Additionally, a valid license for location tracking must be applied to enable the MSE’s location services capabilities. Without this license, the MSE would not be able to provide client and rogue location tracking functionalities. References := ( CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide )

 The issue described indicates that the Angle of Arrival (AoA) data is not being transmitted between the Cisco Wireless LAN Controller (WLC) and the virtual CMX server. To resolve this, the network administrator must ensure that port 2003 is allowed for AoA packets to flow through between the CMX appliances, which is necessary for Hyperlocation data transmission. References: CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide

 When configuring Cisco OfficeExtend Access Points (OEAPs), enabling NAT IP only for office-extend is necessary if the APs are behind a NAT device and need to communicate with the Wireless LAN Controller (WLC) using the internal IP management address. The command config flexconnect office-extend nat-ip-only enable allows the APs to discover and associate with the WLC when the management interface is configured with a NAT address.

In a dual SSID design for BYOD, one SSID is used for provisioning devices, and the other is for network access. It’s important not to enforce an ACL to switch SSIDs after provisioning because this could disrupt the user experience. Instead, the process should be seamless, with the device automatically connecting to the access SSID after provisioning is complete. References := (CCNP Enterprise Wireless Design ENWLSD 300-425 and Implementation ENWLSI 300-430 Official Cert Guide)
