* DiffServ uses the 6-bit Differentiated services Field (DS field) in the IP header for packet classification purposes.

* In the Diffserv model, the marker marks a packet with a value that reflects a forwarding behavior. Marking is the process of placing a value in the packet's header to indicate how to forward the packet to the network. IPQoS contains two marker modules:

/ dscpmk – Marks the DS field in an IP packet header with a numeric value that is called the Differentiated Services codepoint, or DSCP. A Diffserv-aware router can then use the DS codepoint to apply the appropriate forwarding behavior to the packet.

/ dlcosmk – Marks the virtual local area network (VLAN) tag of an Ethernet frame header with a numeric value that is called the user priority. The user priority indicates the class of service (CoS), which defines the appropriate forwarding behavior to be applied to the datagram.

Note:

* Differentiated services or DiffServ is a computer networking architecture that specifies a simple, scalable and coarse-grained mechanism for classifying and managing network traffic and providing quality of service (QoS) on modern IP networks. DiffServ can, for example, be used to provide low-latency to critical network traffic such as voice or streaming media while providing simple best-effort service to non-critical services such as web traffic or file transfers.

* IPQoS, included in Solaris, includes the following modules, which are part of the Differentiated Services (Diffserv) architecture that is defined in RFC 2475:

Classifier

Meter

Marker

IPQoS adds the following enhancements to the Diffserv model:

Flow-accounting module

802.1D datagram marker

D: Example:

# prctl -n task.max-lwps $$

process: 111107: csh

NAME PRIVILEGE VALUE FLAG ACTION RECIPIENT

task.max-lwps

usage 3

privileged 3 - deny -

system 2.15G max deny

F: The following command activates system logging of all violations of task.max-lwps.

# rctladm -e syslog task.max-lwps

#

Note: How to Set the Maximum Number of LWPs for Each Task in a Project

This procedure adds a project named x-files to the /etc/project file and sets a maximum number of LWPs for a task created in the project.

1.Become an administrator.

2. Use the projadd command with the -K option to create a project called x-files. Set the maximum number of LWPs for each task created in the project to 3.

# projadd -K 'task.max-lwps=(privileged,3,deny)' x-files

DE: Link aggregations provide high availability and higher throughput by aggregating multiple interfaces at the MAC layer. IP Multipathing (IPMP) provides features such as higher availability at the IP layer. Both IPMP and Link Aggregation are based on the grouping of network interfaces, and some of their features overlap, such as higher availability. These technologies are however implemented at different layers of the stack, and have different strengths and weaknesses.

E: The IP network multipathing or IPMP is a facility provided by Solaris to provide fault-tolerance and load spreading for network interface cards (NICs). With IPMP, two or more NICs are dedicated for each network to which the host connects.

The IPMP load spreading feature increases the machine's bandwidth by spreading the outbound load between all the cards in the same IPMP group.

Must be in the same network range (see * below).

Different speeds are fine (see ** below).

* An IP multipathing group, or IPMP group, consists of one or more physical interfaces on the same system that are configured with the same IPMP group name. All interfaces in the IPMP group must be connected to the same IP link (A, not B, not C, Not D).

** The same (non-null) character string IPMP group name identifies all interfaces in the group. You can place interfaces from NICs of different speeds within the same IPMP group, as long as the NICs are of the same type. For example, you can configure the interfaces of 100-megabit Ethernet NICs and the interfaces of one gigabit Ethernet NICs in the same group. As another example, suppose you have two 100-megabit Ethernet NICs. You can configure one of the interfaces down to 10 megabits and still place the two interfaces into the same IPMP group.

B: Link aggregations provide high availability and higher throughput by aggregating multiple interfaces at the MAC layer. IP Multipathing (IPMP) provides features such as higher availability at the IP layer. Both IPMP and Link Aggregation are based on the grouping of network interfaces, and some of their features overlap, such as higher availability. These technologies are however implemented at different layers of the stack, and have different strengths and weaknesses.

E: Internet Protocol Network Multipathing (IPMP) provides fault-tolerance and load balancing across multiple network interface cards. By using IPMP, you can configure one or more interfaces into an IP multipathing group. After configuring IPMP, the system automatically monitors the interfaces in the IPMP group for failure. If an interface in the group fails or is removed for maintenance, IPMP automatically migrates, or fails over, the failed interface's IP addresses

Incorrect:

Not A: The same (non-null) character string IPMP group name identifies all interfaces in the group. You can place interfaces from NICs of different speeds within the same IPMP group, as long as the NICs are of the same type.

Not C:If LACP (Link Aggregation Control Protocol) cannot aggregate all the ports that are compatible (for example, the remote system might have more restrictive hardware limitations), then all the ports that cannot be actively included in the channel are put in hot standby state and are used only if one of the channeled ports fails.

Not D: MP is built into Oracle Solaris and does not require any special hardware. Any interface that is supported by Oracle Solaris can be used with IPMP. However, IPMP does impose the following requirements on your network configuration and topology:

/All interfaces in an IPMP group must have unique MAC addresses.

/ All interfaces in an IPMP group must be of the same media type.

/ All interfaces in an IPMP group must be on the same IP link

Example:

The default service model is contract, but may be modified. For this example, we are going to start the service with svc.startd. As a transient service, it will be started once and not restarted by adding the following lines to the manifest:

/>

Note:

svc.startd provides three models of service, which are

* Transient services—These are often configuration services, which require no long-running processes to provide service. Common transient services take care of boot-time cleanup or load configuration properties into the kernel. Transient services are also sometimes used to overcome difficulties in conforming to the method requirements for contract or wait services. This is not recommended and should be considered a stopgap measure.

* Contract services—These are the standard system daemons. They require processes which run forever once started to provide service. Death of all processes in a contract service is considered a service error, which will cause the service to restart.

* Wait services—These services run for the lifetime of the child process, and are restarted when that process exits.

The following list provides a brief description of each default checkpoint in the order the checkpoints are executed in most manifests.

transfer-ips-install – At this checkpoint, the distribution constructor contacts the IPS publishers and adds to the image the packages that are listed in the software_data element of the manifest.

set-ips-attributes – At this checkpoint, the constructor sets the publisher to be used by the installed system. The values set by this checkpoint are not relevant if you are building an automated installation image.

pre-pkg-img-mod – At this checkpoint, the constructor imports into the image the SMF service files that were specified in the configuration element of the manifest. Also, the constructor modifies some files to optimize the image.

URL: http://www.oracle.com/technetwork/articles/servers-storage-admin/o11-118-s11-script-zones-524499.html

Rights profiles – The user_attr, prof_attr, and exec_attr databases are now read-only. These local files databases are assembled from fragments that are located in /etc/user_attr.d, /etc/security/prof_attr.d, and /etc/security/exec_attr.d.

The fragment files are not merged into a single version of the file, but left as fragments. This change enables packages to deliver complete or partial RBAC profiles. Entries that are added to the local files repository with the useradd and profiles commands are added to the local-entries file in the fragment directory.
