Pass the Nutanix Nutanix Certified Professional (NCP) NCP-MCA Questions and answers with CertsForce

When a play is stuck in a suspended state, a common reason is that the playbook was set with a Manual trigger and requires manual intervention to proceed. This can occur if the playbook is designed to pause at a certain step, waiting for an administrator or user to manually approve or provide additional input before continuing.

References:

Nutanix documentation on Playbook Triggers.

Nutanix Best Practices for Playbook Automation.

 A Playbook is a collection of tasks that can be executed based on a trigger, such as a time, a webhook, or a manual action. A Playbook can be used to automate workflows across different systems and services, such as Nutanix Prism, VMs, hosts, and external APIs. A Playbook can also use variables, conditions, and loops to customize the execution logic and data.

In this scenario, the administrator wants to automate the batch processing application on the Linux VM, which can only be controlled by a command on the VM console. The application should run only outside of business hours, and the VM should send REST API calls to Prism to report its status.

The best way to configure a Playbook for this process is to use a Time Trigger, which allows the administrator to specify a schedule for the Playbook execution, such as daily, weekly, or monthly. The Time Trigger can also be configured to run only on certain days or hours, such as weekdays or nights. This way, the administrator can ensure that the Playbook runs only outside of business hours, without requiring any manual intervention.

The Playbook should then have two VM SSH tasks, one to initiate the batch processing application, and one to terminate it. A VM SSH task is a task that executes a command or script on a target VM using SSH. A VM SSH task can be used to control applications or services that do not have a programmatic interface, such as the batch processing application in this scenario. The VM SSH task can also use variables to pass data to or from the command or script, such as the VM name, IP address, or output.

The Playbook should also have a Wait for Some Time task, which is a task that pauses the Playbook execution for a specified duration or until a condition is met. A Wait for Some Time task can be used to ensure that the batch processing application has enough time to complete its work, or to wait for a certain event or state to occur, such as a file creation, a service status, or a VM power state.

The Playbook should also have two REST API tasks, one before and one after the Wait for Some Time task. A REST API task is a task that executes an HTTP request to a specified URL, with optional headers, body, and authentication. A REST API task can be used to interact with external systems or services that expose an API, such as Nutanix Prism in this scenario. The REST API task can also use variables to pass data to or from the HTTP request, such as the VM name, IP address, or response.

The REST API tasks should be configured to send the VM status to Prism, such as the start and end time of the batch processing, the CPU and memory usage, or the output of the application. This way, the administrator can monitor and manage the VM and the application from Prism, without having to connect to the VM console.

The Playbook configuration should look something like this:

Time Trigger: Set the schedule to run daily, only on weekdays, and only at night (e.g., 10 PM to 6 AM).

VM SSH: Set the target VM to the Linux VM, and set the command or script to initiate the batch processing application (e.g., ./batch.sh start).

REST API: Set the URL to the Prism API endpoint, and set the HTTP method, headers, body, and authentication as required. Use variables to pass the VM name, IP address, and start time of the batch processing to the HTTP request (e.g., {"vm_name": "{{vm_name}}", "vm_ip": "{{vm_ip}}", "start_time": "{{start_time}}"}).

Wait for Some Time: Set the duration to the expected time for the batch processing to finish, or set a condition to wait until a certain event or state occurs (e.g., wait until file /tmp/batch.done exists).

REST API: Set the URL to the Prism API endpoint, and set the HTTP method, headers, body, and authentication as required. Use variables to pass the VM name, IP address, end time, and output of the batch processing to the HTTP request (e.g., {"vm_name": "{{vm_name}}", "vm_ip": "{{vm_ip}}", "end_time": "{{end_time}}", "output": "{{output}}"}).

VM SSH: Set the target VM to the Linux VM, and set the command or script to terminate the batch processing application (e.g., ./batch.sh stop).

References:

https://www.nutanix.com/content/dam/nutanix/resources/datasheets/ds-ncp-mca-6-5.pdf

https://www.nutanix.com/content/dam/nutanix/resources/support/ds-ncp-mca.pdf

Scaling VM replica settings allow you to specify the minimum, maximum, and default number of VMs that can be created from a blueprint service. The minimum and default values must be equal to or greater than the number of VMs needed at any time and at time of deployment, which is 2 in this case. The maximum value must be equal to or less than the project quota divided by the VM resources, which is 100/12 = 8 for vCPUs and 300/24 = 12 for memory. The lowest of these two values is the limit for the maximum value, which is 8. Therefore, the only option that meets all the requirements is B. MIN: 2, MAX: 7, Default: 2.

References:

Nutanix Certified Professional - Multicloud Automation (NCP-MCA) Exam Blueprint Guide, page 10, Objective 3.1: Given a scenario, create a blueprint to deploy infrastructure and applications using Self-Service

Nutanix Multicloud Automation Administration (NMCAA), Module 5: Self-Service, Lesson 5.2: Blueprint Design, slide 23: Scaling VM Replica Settings

Nutanix Certified Professional Multicloud Automation (NCP-MCA) 6 Exam, page 10, Objective 3.1: Given a scenario, create a blueprint to deploy infrastructure and applications using Self-Service

In Nutanix Calm, there are two types of blueprints: Single VM and Multi VM. Single VM blueprints are used to define and manage the deployment of individual virtual machines, while Multi VM blueprints are used to manage the deployment of applications that span multiple VMs with defined dependencies and configurations.

References:

Nutanix Calm documentation on Blueprint Types.

Nutanix Best Practices for Blueprint Creation.

Categories are a way of organizing and managing resources in Nutanix Calm. Categories can be used to define access policies, filter resources, and group applications. By creating and assigning the Linux OS Category to the newly-created VM, the administrator can grant access to the OS Team based on their Active Directory Group membership. The OS Team can then use the web SSH console to access the Linux VM from the Calm UI.

References:

Nutanix Support & Insights, section “Categories”

Nutanix Support & Insights, section “Accessing the Web SSH Console”

To deploy Self-Service (formerly Calm), the Nutanix product version that must be compatible is Prism Central. Self-Service relies on Prism Central for orchestration, management, and automation of applications and services across multiple environments.

References:

Nutanix documentation on Self-Service (Calm) Requirements.

Nutanix Best Practices for Deploying Self-Service.

When creating a Runbook in Nutanix Calm, the "Default Endpoint" field is optional. Essential fields such as Name, Project, and Task Name are required to define the Runbook's structure and execution parameters. The Default Endpoint can be specified if there is a preferred initial endpoint for executing tasks, but it is not mandatory.

References:

Nutanix Calm documentation on Runbook Creation.

Nutanix Best Practices for Runbook Management.

One prerequisite for deploying Self-Service (formerly Calm) is that a unique Virtual IP address (VIP) must be configured in the Prism web console cluster that is running on Prism Central. This VIP is necessary for high availability and to ensure that Self-Service can be accessed reliably.

References:

Nutanix Calm documentation on Deployment Requirements.

Nutanix Best Practices for Configuring VIP.

The error message indicates that customization of the guest operating system is not supported. This issue often arises because open-vm-tools is not installed or not running on the Redhat Enterprise Linux VM. open-vm-tools is necessary for vSphere to perform guest customization tasks, such as setting the hostname, IP configuration, and other initialization tasks.

References:

Nutanix documentation on Guest Customization Requirements.

VMware documentation on Installing Open VM Tools.

The error message indicates that the script failed to authenticate to the remote server using CredSSP. CredSSP is a security mechanism that allows a client to delegate its credentials to a remote server for authentication. To use CredSSP, both the client and the server need to enable it and configure the role and the trusted hosts. The command Enable-WSManCredSSP -Role Client enables CredSSP on the client side and specifies the remote server as a trusted host. This command should be added to the script before invoking the Invoke-Command cmdlet that runs the script block on the remote server. The other commands are either irrelevant or incorrect for this scenario. References: Nutanix Calm: PowerShell Scripts - Read the Docs and Enable-WSManCredSSP (Microsoft.PowerShell.Management) - PowerShell | Microsoft Docs.
