For Option A:In Fortinet BGP (and standard BGP), when a prefix is displayed with an "i" (lowercase i) in the Path column, it represents an internal prefix that originated from the local router, typically configured via the BGP "network" command. In the exhibit, the prefix 10.20.30.0/24 is listed with a Path value of i, indicating it was injected into BGP by the local router using the network statement, not via redistribution from another routing protocol. The same logic applies to i as documented: "Origin code 'i' means the route was injected via the network command."
For Option D:The get router info bgp network output is a summary table displaying both local and received BGP routes. It lists all known routes to the BGP process, whether received from peers or originated locally. The exhibit shows all BGP prefixes known to the local router, matching the official admin guide’s description of this command’s output.
Explanation for B and C:
The phrase “legacy route advertisement” is not formalized in BGP documentation or Fortinet’s admin guide; the output uses standard BGP mechanics.
If a route was redistributed into BGP from another routing protocol, the Path field would display a "?" (question mark) for incomplete (redistributed) origin. Here the /24 route has "i" so it is NOT a redistribution.
[References:, FortiOS Administration Guide: BGP Configuration and Route Table Interpretation, Official BGP Command Reference: Show BGP Network, Path Codes, Route Origination Indicators, ]
