The following are the integration frameworks that have been released for ABAP cloud development:

SOAP consumption: This framework allows you to consume SOAP web services from ABAP cloud applications. You can use the ABAP Development Tools in Eclipse to create a service consumption model based on a WSDL file or URL. The service consumption model generates the required ABAP artifacts, such as proxy classes, data types, and constants, to access the web service. You can then use the proxy classes to call the web service operations from your ABAP code1

Business Events: This framework allows you to publish and subscribe to business events from ABAP cloud applications. Business events are messages that represent a change in the state of a business object or process. You can use the ABAP Development Tools in Eclipse to create a business event definition based on a CDS view entity or a projection view. The business event definition specifies the event key, the event payload, and the event metadata. You can then use the ABAP Messaging Channel (AMC) framework to publish and subscribe to business events using the AMC API2

OData services: This framework allows you to expose and consume OData services from ABAP cloud applications. OData is a standardized protocol for creating and consuming RESTful APIs. You can use the ABAP RESTful Application Programming Model (RAP) to create OData services based on CDS view entities or projection views. The RAP framework generates the required OData metadata and runtime artifacts, such as service definitions, service bindings, and service implementations. You can then use the SAP Gateway framework to register and activate your OData services. You can also use the ABAP Development Tools in Eclipse to consume OData services from other sources using the service consumption model3

The other integration frameworks are not released for ABAP cloud development, as they are either not supported or not recommended for cloud scenarios. These frameworks are:

CDS Views: CDS views are not an integration framework, but a data modeling framework. CDS views are used to define data models based on database tables or other CDS view entities. CDS views can have associations, aggregations, filters, parameters, and annotations. CDS views can also be used as the basis for other integration frameworks, such as OData services or business events4

Business Add-ins (BAdls): BAdls are not supported for ABAP cloud development, as they are part of the classic ABAP enhancement framework. BAdls are used to implement custom logic in predefined enhancement spots in the standard SAP code. BAdls are not compatible with the cloud strategy and the clean core paradigm, as they modify the SAP code and can cause upgrade and maintenance issues. For ABAP cloud development, SAP recommends using the key user extensibility tools or the side-by-side extensibility approach instead of BAdls.

References: Consuming SOAP Services - ABAP Keyword Documentation, Business Events - ABAP Keyword Documentation, OData Services - ABAP Keyword Documentation, CDS Data Model Views - ABAP Keyword Documentation, [Business Add-Ins (BAdIs) - ABAP Keyword Documentation]

The following are the explanations for each statement:

A: This statement is valid. go_ifl may call method ml with go_ifl->ml(). This is because go_ifl is a data object of type REF TO ifl, which is a reference to the interface ifl. The interface ifl defines a method ml, which can be called using the reference variable go_ifl. The class cll implements the interface ifl, which means that it provides an implementation of the method ml. The data object go_ifl is assigned to a new instance of the class cll using the NEW operator and the inline declaration operator @DATA. Therefore, when go_ifl->ml() is called, the implementation of the method ml in the class cll is executed123

B: This statement is valid. Instead of go_cll = NEW #(…) you could use go_ifl = NEW cll(…). This is because go_ifl is a data object of type REF TO ifl, which is a reference to the interface ifl. The class cll implements the interface ifl, which means that it is compatible with the interface ifl. Therefore, go_ifl can be assigned to a new instance of the class cll using the NEW operator and the class name cll. The inline declaration operator @DATA is optional in this case, as go_ifl is already declared. The parentheses after the class name cll can be used to pass parameters to the constructor of the class cll, if any123

E: This statement is valid. go_ifl may call method m2 with go_ifl->m2(…). This is because go_ifl is a data object of type REF TO ifl, which is a reference to the interface ifl. The class cll implements the interface ifl, which means that it inherits all the components of the interface ifl. The class cll also defines a method m2, which is a public method of the class cll. Therefore, go_ifl can call the method m2 using the reference variable go_ifl. The method m2 is not defined in the interface ifl, but it is accessible through the interface ifl, as the interface ifl is implemented by the class cll. The parentheses after the method name m2 can be used to pass parameters to the method m2, if any123

The other statements are not valid, as they have syntax errors or logical errors. These statements are:

C: This statement is not valid. go_cll may call method ml with go_cll->ifl~ml(). This is because go_cll is a data object of type REF TO cll, which is a reference to the class cll. The class cll implements the interface ifl, which means that it inherits all the components of the interface ifl. The interface ifl defines a method ml, which can be called using the reference variable go_cll. However, the syntax for calling an interface method using a class reference is go_cll->ml(), not go_cll->ifl~ml(). The interface component selector ~ is only used when calling an interface method using an interface reference, such as go_ifl->ifl~ml(). Using the interface component selector ~ with a class reference will cause a syntax error123

D: This statement is not valid. Instead of go_cll = NEW #() you could use go_ifl = NEW #(…). This is because go_ifl is a data object of type REF TO ifl, which is a reference to the interface ifl. The interface ifl cannot be instantiated, as it does not have an implementation. Therefore, go_ifl cannot be assigned to a new instance of the interface ifl using the NEW operator and the inline declaration operator @DATA. This will cause a syntax error or a runtime error. To instantiate an interface, you need to use a class that implements the interface, such as the class cll123

References: INTERFACES - ABAP Keyword Documentation, CLASS - ABAP Keyword Documentation, NEW - ABAP Keyword Documentation

When processing an internal table with the statement LOOP AT itab… ENDLOOP, the system variable that contains the current row number is sy-tabix. The sy-tabix variable is a predefined field of the system structure sy that holds the index or the row number of the current line in an internal table loop. The sy-tabix variable is initialized with the value 1 for the first loop pass and is incremented by 1 for each subsequent loop pass. The sy-tabix variable can be used to access or modify the current line of the internal table using the index access12.

References: 1: LOOP AT itab - ABAP Keyword Documentation - SAP Online Help 2: System Fields - ABAP Keyword Documentation - SAP Online Help

In a RESTful Application Programming (RAP) application, you can bind a CDS view to create a value help in the following objects:

Data model view: A data model view is a CDS view that defines the data structure and the associations of an entity in the RAP application. You can use the annotation @Consumption.valueHelpDefinition to bind a value help provider CDS view to an element of the data model view. The value help provider CDS view must contain the key fields of the value help entity and the fields that are displayed in the value help dialog. The value help annotation specifies the entity name, the element name, and optionally the additional binding conditions for the value help provider1.

Metadata Extension: A metadata extension is a CDS view that extends the metadata of another CDS view without changing its data structure. You can use the annotation @MetadataExtension.extendView to specify the target CDS view that you want to extend. You can then use the same annotation @Consumption.valueHelpDefinition to bind a value help provider CDS view to an element of the target CDS view. The metadata extension allows you to add value help definitions to existing CDS views without modifying them2.

Projection View: A projection view is a CDS view that defines the projection of another CDS view. You can use the annotation @AbapCatalog.sqlViewType: #PROJECTION to specify that the CDS view is a projection view. You can then use the same annotation @Consumption.valueHelpDefinition to bind a value help provider CDS view to an element of the projection view. The projection view allows you to add value help definitions to projected elements of another CDS view3.

You cannot bind a value help provider CDS view to a behavior definition or a service definition, because these objects do not define the data structure or the metadata of an entity in the RAP application. A behavior definition defines the behavior and the validation rules of an entity, such as the create, read, update, and delete (CRUD) operations, the draft handling, the authorization checks, and the side effects4. A service definition defines the service exposure and the service binding of an entity, such as the protocol, the version, the namespace, and the service name5.

References: 1: Value Help with Additional Binding | SAP Help Portal 2: Metadata Extensions - ABAP Keyword Documentation 3: Projection Views - ABAP Keyword Documentation 4: Behavior Definition - ABAP Keyword Documentation 5: Service Definition - ABAP Keyword Documentation
