The exhibit shows a graph of the client’s roaming history over time. The x-axis represents the time and the y-axis represents the access point ID. Each dot on the graph indicates a roam event where the client switched from one access point to another.

The graph shows that the client roamed between different access points multiple times within a short period of time. This indicates that the client was experiencing frequent roams between different access points, which could affect its network performance and user experience.

According to the Initial AP Connection and VLANs & Static IP addresses - Mist document1, when a Juniper Mist AP boots up for the first time, it will expect to see a trunked port or the native VLAN=1 and will send a DHCP request on that VLAN. The AP will attempt to connect to the Mist cloud using port 443, which is the default HTTPS port.

According to the exhibit, the WLAN has a minimum basic rate of 24 Mbps for both 2.4 GHz and 5 GHz bands. This corresponds to the high-density data rate setting in Mist, which disables all data rates below 24 Mbps. This setting is recommended for high density designs, where clients have enough signal strength and quality to operate at higher rates.

When deploying three WLAN 2.4 GHz networks in your US-based site while ensuring that each network frequency is unique and does not overlap with other frequency channels, you should use OFDM channels 1, 6 and 11. So the correct answers are B.1, D.6, and A.11.

In Juniper Networks Mist AI Wireless, the strength and quality of a client’s wireless connection are primarily evaluated using RSSI (Received Signal Strength Indicator) and SNR (Signal-to-Noise Ratio). These two metrics are core inputs into multiple Wireless Assurance SLEs, including Coverage and Throughput, and are reliable indicators when determining which client has the weakest WLAN connection.

From the exhibit, the key metrics for each client are:

Client 1: RSSI –81 dBm, SNR 11 dB

Client 2: RSSI –71 dBm, SNR 21 dB

Client 3: RSSI –67 dBm, SNR 25 dB

Client 4: RSSI –70 dBm, SNR 22 dB

In wireless design, lower (more negative) RSSI values indicate weaker signal strength, and lower SNR values indicate poorer signal quality due to higher relative noise. Among all listed clients, Client 1 clearly has the weakest connection, as it has both:

The lowest RSSI (–81 dBm), indicating it is farthest from the AP or experiencing significant attenuation.

The lowest SNR (11 dB), which suggests the signal is only marginally stronger than the background noise.

Mist best practices typically consider RSSI values below –70 dBm and SNR values below ~20 dB as suboptimal for reliable performance, especially for higher modulation schemes. Client 1 falls well below these thresholds, making it the most likely to experience low data rates, retransmissions, and degraded user experience.

Mist AI would flag this client as having poor coverage and may recommend actions such as:

Improving AP placement or density

Adjusting RF power or channel plans

Enforcing minimum RSSI thresholds

Therefore, based on both RSSI and SNR, Client 1 has the weakest WLAN connection, making Option D the correct answer.

According to the Cisco Catalyst 9800 Series Wireless Controller Software Configuration Guide2, you can create a new site configuration under the location hierarchy level in the Juniper Mist UI. A site is a logical grouping of devices based on physical location or other criteria.

In the context of Juniper Mist WxLAN Security and Rogue AP detection, Mist AI categorizes surrounding access points into specific buckets based on their behavior and their connection to the local network infrastructure. Understanding the distinction between a Rogue AP and a Honeypot AP is essential for proper security posture.

A Honeypot AP (C) is specifically defined as an unauthorized access point that is broadcasting one of your organization's protected SSIDs (or a very similar one) but is not physically connected to your wired network. This is a classic "Evil Twin" attack where a malicious actor attempts to trick corporate users into connecting to a fake signal. Because the clients’ devices are often programmed to auto-associate with known SSIDs, they may unknowingly connect to the Honeypot AP, allowing the attacker to intercept traffic, perform man-in-the-middle attacks, or harvest credentials. Mist APs use their dedicated scanning radio (found in the AP43, AP45, and similar models) to constantly monitor the airwaves for these spoofed SSIDs.

In contrast, a Rogue AP (D) is an unauthorized AP that is physically connected to your corporate wired network (LAN). Mist identifies these by correlating the MAC addresses seen on the air with those seen on the wired switch ports. A Neighbor AP (B) is simply an AP from a nearby business that is broadcasting its own unique SSID and is not connected to your network; these are ignored by security alerts.

By classifying the threat as a Honeypot, Mist AI informs the administrator that the threat is external to the wired infrastructure but poses a direct risk to client data. Mist can even be configured to take automated action, such as sending de-authentication frames to prevent clients from successfully staying connected to the malicious Honeypot AP.

Mist Radio Resource Management (RRM) performs several functions including transmit power control and channel assignment which help optimize wireless network performance by dynamically adjusting radio settings based on changing environmental conditions.So,the correct answers are A.transmit power control and C.channel assignment

According to the Cisco Catalyst 9800 Series Wireless Controller Software Configuration Guide1, two functions of Mist Radio Resource Management (RRM) are:

Transmit power control, which adjusts the transmit power of APs based on their coverage area and interference level.

Channel assignment, which assigns channels to APs based on their location and interference level.

A firewall is a network security system that monitors and controls incoming and outgoing network traffic based on predetermined security rules. It typically establishes a barrier between a trusted internal network and an untrusted external network, such as the Internet .

In the IEEE 802.1X authentication process, the AP acts as an authenticator.

According to the Lecture 5 - Security - Part 1 document, the AP’s role in the IEEE 802.1X authentication process is to act as an authenticator. This means that the AP acts as a gatekeeper between the client device (supplicant) and the RADIUS server (authentication server). The AP forwards authentication messages between the supplicant and the server and grants or denies network access based on the server’s response.
