Pass the Huawei HCIE-WLAN H12-351_V1.0 Questions and answers with CertsForce

In a classroom scenario. If the walls are made of reinforced concrete, the signal attenuation Is high. In this case, you are advised to test the attenuation during the site survey. Additionally, pay attention to the locations of ELV rooms in the teaching building.

In an office scenario, the load-bearing columns and partitions affect the signal coverage. If an integrated ceiling is used, deploy APs near maintenance entrances. If a metal ceiling is used, mount APs on the ceiling or wall.

In a ward-round scenario, high requirements are posed on the coverage field strength, roaming effect, and bandwidth. Determine the interference of medical equipment and the areas where Wi-Fi signals are not allowed.

In a stadium scenario, the onsite environment is complex and cabling is difficult. Therefore, confirm with the property management company about ELV rooms and cabling. If the transmission distance is too long, consider deploying more switches. During the survey, focus on the interference between APs and AP mounting modes.

The local AC and Navi AC must have the same service VLAN, SSID, user isolation mode, and authentication mode in their VAP profiles.

The software versions of the local AC and Navi AC can be different.

Dual-link backup can be deployed between the local AC and Navi AC.

Inter-Navi AC roaming is supported.

TRUE

FALSE

SSID

Security policy

BSSID

VAP

Although the static VXLAN tunnel mode supports the distributed gateway scenario, the configuration involves a heavy workload and is complex to adjust.

A static VXLAN tunnel uses related protocols on the control plane, consuming device resources.

If N devices need to establish VXLAN tunnels, you need to manually configure the ingress replication list up to N x (N-l)/2 times.

Remote MAC addresses can be learned only through data flooding.

In EAP termination mode, an access device encapsulates EAP packets sent by an 802. IX client Into RADIUS packets, without processing the data in the EAP packets.

In EAP relay mode, an access device extracts information from EAP packets, encapsulates the information into RADIUS packets, and sends the RADIUS packets to an authentication server.

In EAP termination mode, an access device extracts client authentication information from the EAP packets sent by a client and encapsulates the information using the standard RADIUS protocol. The access device supports only the EAP MD5-Challenge authentication method.

The EAP termination mode simplifies the processing on an access device and supports various authentication methods. However, this mode requires an authentication server to support EAP and have high processing capability.
