Pass the Huawei HCIE-WLAN H12-351_V1.0 Questions and answers with CertsForce

According to the Huawei documents and resources, the encapsulation formats used for EAP termination in 802.1X authentication are as follows:

B. EAPoL: The client and access device exchange information using EAPoL packets across the LAN2.

C. EAPoR: The access device directly encapsulates the received EAP packets into RADIUS using EAP over RADIUS (EAPoR) packets2.

Therefore, B and C are the correct answers. References: 2: https://support.huawei.com/enterprise/en/doc/EDOC1100086527

Attack defense is a feature that allows APs to analyze the contents and behaviors of incoming packets on ports to determine whether packets have attack characteristics. The APs then take defense measures on the packets that have attack characteristics, such as discarding them or limiting their rate. Attack defense can defend against spoofing packet attacks, malformed packet attacks, fragmentation attacks, and flood attacks.

References: https://support.huawei.com/enterprise/en/doc/EDOC1100058940/8a8f1c9b/attack-defense

B is false because a static VXLAN tunnel does not use any protocols on the control plane, saving device resources.

References: https://support.huawei.com/enterprise/en/doc/EDOC1100058940/8a8f1c9b/static-vxlan-tunnel

In Huawei’s smart roaming solution, the WAC can discover and maintain neighboring AP entries of STAs by using two methods: passive listening and active scanning. Passive listening means that the AP listens to the Probe frames sent by STAs and reports them to the WAC. Active scanning means that the AP periodically and proactively scans neighboring APs of STAs and reports them to the WAC.

References: https://support.huawei.com/enterprise/en/doc/EDOC1100058940/8a8f1c9b/smart-roaming

According to the Huawei documents and resources, the network planning suggestions for the solutions are as follows:

Asset management: The RFID signal coverage distance is 25 m. Therefore, RFID signal coverage must be considered during AP deployment planning. Attach RFID tags on the surface or top of assets to prevent signals from being blocked.

ESL: Shelves may be blocked in application scenarios. Therefore, shelf blocking must be considered during network planning. The shelves can be deployed in aisles to minimize obstacles toward integrated base stations.

Smart healthcare: For applications that support regional positioning, positioning devices need to be deployed at key entrances and exits based on service requirements.

Therefore, Asset management - 2, ESL - 1, Smart healthcare - 3 is the correct answer. References: : https://support.huawei.com/enterprise/en/doc/EDOC1100158948/9a0d5c37/asset-management : https://support.huawei.com/enterprise/en/doc/EDOC1100158948/9a0d5c37/esl : https://support.huawei.com/enterprise/en/doc/EDOC1100158948/9a0d5c37/smart-healthcare

After multicast-to-unicast conversion is enabled on an AP’s air interface, the destination MAC address of multicast packets sent over the air interface is changed to the MAC address of a STA that has joined the multicast group. This improves the transmission efficiency and reliability of multicast packets.

References: https://support.huawei.com/enterprise/en/doc/EDOC1100058940/8a8f1c9b/multicast-to-unicast-conversion

B and E are not parameters recorded by iMaster NCE-CampusInsight for interference analysis. The other options are parameters recorded by iMaster NCE-CampusInsight to comprehensively record and analyze interference.

References: https://support.huawei.com/enterprise/en/doc/EDOC1100058940/8a8f1c9b/interference-analysis
