To establish a keepalive connection between two Aruba CX 8325 switches for VSX configuration, you need to use a routed port in custom VRF. A routed port is a physical port that acts as a layer 3 interface and does not belong to any VLAN. A custom VRF is a virtual routing and forwarding instance that provides logical separation of routing tables. By using a routed port in custom VRF, you can isolate the keepalive traffic from other traffic and prevent routing loops or conflicts. The other options are incorrect because they either do not use a routed port or do not use a custom VRF. References: https://www.arubanetworks.com/techdocs/AOS-CX/10.04/HTML/5200-6728/bk01-ch07.html https://www.arubanetworks.com/techdocs/AOS-CX/10.04/HTML/5200-6728/bk01-ch02.html

A failed VLAN Probe indicates that the gateway cluster members do not have the required common Layer 2 connectivity for those VLANs. When the VLAN probes fail, the relationship between cluster members is effectively treated as L3-connected rather than L2-connected. Aruba’s clustering documentation distinguishes these two operating conditions very clearly.

For an L3-connected cluster, only APs are fully replicated. Client/user information is not fully synchronized between cluster members, and high-value application sessions are not synchronized. Aruba’s official ArubaOS 8 Fundamentals Guide summarizes the distinction as follows: for L2-connected members, APs and clients are fully replicated, users and high-value sessions are synchronized, and failover occurs without deauthentication. For L3-connected members, only APs are fully replicated, users and high-value sessions are not synchronized, and users can be deauthenticated during failover. Aruba Networks

Therefore, option B precisely describes the outcome when VLAN probing fails across the required VLANs. Option A requires L2-connected clustering. Option C describes full L2 redundancy. Option D is reversed: L3-connected operation does not provide hitless client failover and users may be deauthenticated during a gateway failure. Aruba Networking

Study Guide Topics: Gateway Clustering, VLAN Probe, L2-Connected vs. L3-Connected Clusters, AP/Client State Synchronization, Stateful Failover, High-Value Session Synchronization.

OFDMA (Orthogonal Frequency Division Multiple Access) is a technology that can minimize client latency in a high-density environment by eliminating contention overhead by dedicating subcarriers to clients. OFDMA allows multiple clients to transmit simultaneously on different subcarriers within the same channel, reducing contention and increasing efficiency. MU-MIMO (Multi-User Multiple Input Multiple Output) is a technology that allows multiple clients to transmit simultaneously on different spatial streams within the same channel, but it does not eliminate contention overhead. QWMM (Quality of Service Wireless Multimedia) is a technology that prioritizes traffic based on four access categories, but it does not eliminate contention overhead. Channel Bonding is a technology that combines two adjacent channels into one wider channel, increasing bandwidth but not eliminating contention overhead. References: https://www.arubanetworks.com/assets/ds/DS_AP510Series.pdf https://www.arubanetworks.com/assets/wp/WP_WiFi6.pdf

Proves knowledge of the PMK

Exchanges messages for generating PTK

Distributes an encrypted GTK to the client

Sets first initialization vector (IV)

Aruba 9004 gateway supports ZTP on port G0/0/0 by default1. If the gateway is connected to a different port, such as G0/0/V1, it will not be able to communicate with Aruba Activate and Aruba Central, which are required for ZTP2. Moreover, port G0/0/V1 is configured as a DHCP server by default, which can cause IP address conflicts with the existing network3. Therefore, the technician should move the cable on the gateway to port G0/0/0, which will allow the gateway to obtain an IP address from the network DHCP server and start the ZTP process. The other options are not correct because they will not solve the issue or enable ZTP. For example, option D will not work because factory defaulting and rebooting the gateway will not change the port configuration or behavior3.

The Aruba CX 6400 switch is a modular switch that supports high-performance and high-density Ethernet switching for campus and data center networks. One of the features that distinguishes the Aruba CX 6400 switch from most typical campus switches is virtual output queueing (VOQ). VOQ is a technique that implements large ingress packet buffers on each port to prevent head-of-line blocking and packet loss due to congestion2. VOQ allows each port to have multiple queues for different output ports and prioritize packets based on their destination and QoS class2. VOQ enables the Aruba CX 6400 switch to achieve high throughput and low latency for various traffic types and scenarios. References: 2 https://www.arubanetworks.com/assets/ds/DS_CX6400Series.pdf

802.11k is a standard that provides mechanisms for APs and clients to dynamically measure the available radio resources in a wireless network. 802.11k defines radio resource management (RRM) functions, such as neighbor reports, link measurement, beacon reports, etc., that allow APs and clients to exchange information about the RF environment and make better roaming decisions. The other options are incorrect because they describe other standards, such as 802.11r, 802.11v, or 802.11ax. References: https://www.arubanetworks.com/assets/wp/WP_WiFi6.pdf https://www.arubanetworks.com/assets/ds/DS_AP510Series.pdf

Splitting a larger OSPF area into a number of smaller areas has several advantages for network scalability and performance. Some of these advantages are:

It increases stability by limiting the impact of topology changes within an area. When a link or router fails in an area, only routers within that area need to run the SPF algorithm and update their routing tables. Routers in other areas are not affected by the change and do not need to recalculate their routes.

It reduces processing overhead by reducing the size and frequency of link-state advertisements (LSAs). LSAs are packets that contain information about the network topology and are flooded within an area. By dividing a network into smaller areas, each area has fewer LSAs to generate, store, and process, which saves CPU and memory resources on routers.

It reduces bandwidth consumption by reducing the amount of routing information exchanged between areas. Routers that connect different areas, called area border routers (ABRs), summarize the routing information from one area into a single LSA and advertise it to another area. This reduces the number of LSAs that need to be transmitted across area boundaries and saves network bandwidth.
