An application owner is experiencing performance issues for their application. Unisphere for PowerMax is showing the storage group is compliant with the current Service Level. A Service Level is a predefined set of performance attributes that can be applied to a storage group to ensure consistent and predictable performance. A Service Level specifies a target response time, an upper response time limit, and a lower response time limit for the storage group. If the application owner wants to improve theperformance of their application, they can adjust the Service Level to a higher level of service, which will provide lower response times and higher priority for the storage group. Unisphere for PowerMax provides five predefined Service Levels: Diamond, Platinum, Gold, Silver, and Bronze, as well as an Optimized option that automatically adjusts the Service Level based on workload characteristics. The application owner can choose a higher Service Level from these options or create a custom Service Level with their own performance parameters.

References:

Dell EMC PowerMax: Service Levels for PowerMaxOS

Dell Unisphere for PowerMax 10.0.0 Product Guide

In a Concurrent SRDF/Star configuration failure, the first step to recover is to switch to the 1st Target Site. This is because in a Concurrent SRDF/Star configuration, there are two target sites and one source site. If there’s a failure, the source site can switch to either of the target sites based on the business continuity plan1. References: Dell EMC Solutions Enabler 9.2 SRDF Family CLI User Guide

The two factors that define Capacity Management are I/O capacity and storage capacity. I/O capacity refers to the ability of the system to handle the incoming and outgoing data traffic from the hosts or applications. Storage capacity refers to the amount of disk space available to store the data. Capacity Management is the process of planning, monitoring, and optimizing the use of these resources to ensure optimal performance, availability, and efficiency of the system.

References:

Dell EMC PowerMax: Family Overview

System Resource Usage

In an SRDF/Metro configuration, if the host is cross-connected and the R2 device becomes Not Ready, the host continues to have read/write access to the R1 device12. This is because SRDF/Metro is designed to provide high availability and continuous data access. If one device becomes inaccessible, the host can still access the other device12. References: SRDF/Metro | SAP Landscape Consolidation with Dell Components, Understanding bias | Dell EMC PowerMax and VMAX All Flash: SRDF/Metro Overview and Best Practices

 In a SRDF/Metro deployment in a clustered host configuration, when the RDF link state is partitioned and the R1 side has full read/write capability to the application, the R2 device also has full read/write capability to the application. With SRDF/Metro, both R1 and R2 devices may then appear as a single virtual device across the two SRDF paired arrays for host presentation. With both the R1 and R2 devices being accessible, the host or hosts (in the case of a cluster) can read and write to both R1 and R2 devices with SRDF/Metro ensuring that each copy remains current, consistent, and addressing any write conflicts which may occur between the paired SRDF devices23. References: Dell EMC PowerMax and VMAX All Flash: SRDF/Metro Overview and Best Practices, Deploying Dell EMC SRDF/Metro Smart DR with Microsoft SQL Server for Physical and Virtual Environments

R11 devices are included in a Cascaded SRDF environment. In a cascaded SRDF configuration, the R1 device at the primary site is paired with an R11 device at the secondary site, which is then paired with an R2 device at the tertiary site2. References: NDM overview | Dell EMC PowerMax and VMAX: Non-Disruptive Migration Best Practices and Operational Guide | Dell Technologies Info Hub

If an administrator implemented SYMACLs on a PowerMax using host-based Access IDs and is no longer able to run SYMCLI commands against the volumes belonging to a host, one possible reason could be that the SYMAPI options file was manually modified with the wrong host ID. The SYMAPI options file contains configuration settings for Solutions Enabler, including host IDs for access control. If this file is incorrectly modified, it could prevent the administrator from running SYMCLI commands against certain volumes34. References: Dell EMC PowerMax and VMAX All Flash: Embedded Management, Role Based Access Control on PowerMax – Storage Intelligence

Unisphere for PowerMax and Solutions Enabler have different ways of managing user permissions. Unisphere has a more explicit authentication mechanism for users, where each user must have a username and password to log in to the Unisphere interface. Unisphere also supports role-based access control (RBAC), where each user can be assigned one or more roles that define their level of access to the storage system resources and operations. Unisphere maintains the user and role information in a symauth database, which can be shared with Solutions Enabler. Solutions Enabler, on the other hand, uses the operating system user credentials to authenticate users. Solutions Enabler does not require users to have a username and password to run commands, but it checks the symauth database to verify if the user has the appropriate role to perform the requested operation. Solutions Enabler also supports RBAC, where each user can be assigned up to four roles that define their level of access to the storage system resources and operations.

References:

Unisphere for PowerMax User Management

Solutions Enabler User Management

During a Non-Disruptive Migration (NDM), when the migration is committed, the host access to the source array is removed by deleting the masking view. The masking view is a logical grouping of host initiators, storage ports, and a storage group (which contains volumes). Deleting the masking view removes the host’s access to the volumes on the source array12. References: Dell EMC PowerMax and VMAX: Non-Disruptive Migration Best Practices and Operational Guide, VMAX/PowerMax Non-Disruptive Migration (NDM) for the IBMi host platform | Dell US Support Knowledge Base Article

Data Domain is the only external storage that can be connected to PowerMax using DX emulation. DX emulation is a specialized back-end DA emulation that handles SAN attached disks. DX directors are configured on existing PowerMax front-end Fibre Channel ports and are required to be implemented in pairs for high availability. DX emulation is used to support ProtectPoint technology, which integrates primary storage with Data Domain protection storage to accelerate backup and recovery. Therefore, answer A is correct1.

B, C, and D are incorrect because they are not external storage that can be connected to PowerMax using DX emulation. Unity (B), PowerStore ©, and Compellent (D) are primary storage arrays that do not support ProtectPoint technology or DX emulation.
