The study guide explicitly explains the FortiGuard flags shown by diagnose debug rating:
D = Default
“IP addresses of servers received from DNS resolution”
It then clarifies even more specifically:
“D = The IP address FortiGate got when resolving the service.fortiguard.net name (usually two or three servers have this flag, if the administrator didn't overwrite the FortiGuard FQDN or IP address in the FortiGate configuration)”
In the exhibit, among the answer choices, the IP address marked with the D flag is 208.91.112.194 . Therefore, that is the IP FortiGate got from resolving service.fortiguard.net.
Why the other options are wrong:
B. 209.22.147.36 is not the correct choice because in the exhibit it is not the DNS-resolution entry identified by the D flag
C. 64.26.151.37 has no D flag
D. 96.45.33.65 has no D flag
So the verified answer is: A .
