Cisco Implementing and Operating Cisco Service Provider Network Core Technologies (350-501 SPCOR) 350-501 Question # 26 Topic 3 Discussion
350-501 Exam Topic 3 Question 26 Discussion:
Question #: 26
Topic #: 3
Refer to the exhibit.
An engineer must configure router R2 as the new P router in the network. Which configuration must be applied to R2 to enable LDP-IGP Sync on its L2 IS-IS adjacencies?
In the context of Implementing and Operating Cisco Service Provider Network Core Technologies, LDP-IGP Synchronization is configured to ensure that the IGP and LDP convergences are synchronized. Option C is correct because it shows the configuration where router ISIS 1 is being configured with MPLS LDP sync, but not on a specific interface, ensuring that LDP is operational on all interfaces where IS-IS is enabled before routes are advertised. References := Cisco
