300-510 Exam Topic 2 Question 14 Discussion:
Question #: 14
Topic #: 2

300-510 Question 14

300-510 Question 14

Refer to the exhibit. A network engineer is investigating a report of packet drops between the branch site and the central site.

    The two sites are connected via OSPF and RSVP-TE tunnels.

    Traffic from the central site to the branch site is passing normally.

    Technicians at both sites successfully ping the loopback IP addresses on routers R1 and R2.

Which configuration corrects the packet-drop problem?

300-510 Question 14


A.

Option A


B.

Option B


C.

Option C


D.

Option D
