Refer to the exhibit. An engineer must ensure that the QoS design guarantees bandwidth for the applications, and an application can request a particular type of service to support its delay requirements. Which solution must the engineer select?
IntServ with RSVP is the correct model when an application must request a specific service level and receive guaranteed bandwidth or delay treatment. Cisco describes the Integrated Services model as a flow-based QoS architecture in which applications signal their resource requirements to the network. RSVP is the signaling protocol used to reserve resources along the path. This differs from DiffServ, which marks packets and applies per-hop behavior without creating per-flow reservations. The question states that the application can request a particular type of service to support its delay requirements and that bandwidth must be guaranteed. Those are classic IntServ and RSVP characteristics. DiffServ with DSCP is scalable and widely used in enterprise networks, but it cannot guarantee resources end to end unless every hop is engineered and provisioned accordingly. IntServ with DSCP is not the standard model because RSVP is the reservation mechanism. Reference topics: Integrated Services, RSVP, resource reservation, guaranteed service, QoS architecture, delay-sensitive applications.
